Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Menu 21
Unidrive SP Advanced User Guide 319
Issue Number: 7 www.controltechniques.com
21.07 Rated current
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
12 1 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to RATED_CURRENT_MAX A
Default
Open-loop, Closed-loop vector, Servo,
Regen
max heavy duty current (Pr 11.32)
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.07
Update rate Background read
21.08 Rated load rpm
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Closed-loop vector DP=2
Range
Open-loop,
Closed-loop vector, Servo
0 to 180,000 rpm
0.00 to 40,000.00 rpm
Default
Open-loop,
Closed-loop vector
EUR: 1,500, USA: 1,800
EUR: 1,450.00, USA: 1,770.00
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.08
Update rate Background read
21.09 Rated voltage
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range Open-loop, Closed-loop vector, Servo 0 to AC_VOLTAGE_SET_MAX V
Default Open-loop, Closed-loop vector, Servo
200V rating drive: 230V
400V rating drive: EUR: 400V, USA: 460V
575V rating drive: 575V
690V rating drive: 690V
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.09
Update rate Level 4 read
21.10 Rated power factor
Drive modes Open-loop, Closed-loop vector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3111
Range Open-loop, Closed-loop vector 0.000 to 1.000
Default Open-loop, Closed-loop vector 0.850
Normal
parameter
Open-loop, Closed-loop vector Pr 5.10
Update rate Background read
