Control Techniques unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Unidrive SP Advanced User Guide 333
Issue Number: 7 www.controltechniques.com
Table 6-5 Parameter set-up to reproduce Macro 2 on a Unidrive SP
Parameter
Value
OL CL
7.14 T7 analog input 2 destination Pr 0.00
8.21 T24 digital I/O 1 source / destination Pr 9.26
8.25 T28 digital input 5 destination Pr 9.27
8.26 T26 digital input 6 destination Pr 1.41
8.31 T24 digital I/O 1 output select OFF (0)
8.39 T28 & T29 digital input auto selection disable On (1)
9.04 Logic function 1 source 1 Pr 9.22
9.07 Logic function 1 source 2 On (1)
9.10 Logic function 1 destination Pr 1.10
9.14 Logic function 2 source 1 Pr 8.02
9.17 Logic function 2 source 2 invert On (1)
9.20 Logic function 2 destination Pr 9.28
9.25 Motorised pot destination Pr 1.37
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 1.05
11.05 Define Pr 0.15 Pr 2.04
11.06 Define Pr 0.16 Pr 6.01
11.07 Define Pr 0.17 Pr 8.17
11.08 Define Pr 0.18 Pr 2.06
11.09 Define Pr 0.19 Pr 2.07
11.10 Define Pr 0.20 Pr 1.29
11.11 Define Pr 0.21 Pr 1.30
11.12 Define Pr 0.22 Pr 1.31
11.13 Define Pr 0.23 Pr 1.32
11.14 Define Pr 0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 9.28
11.16 Define Pr 0.26 Pr 9.03
11.17 Define Pr 0.27 Pr 9.21
11.18 Define Pr 0.28 Pr 9.22
11.19 Define Pr 0.29 Pr 9.23
11.20 Define Pr 0.30 Pr 9.24
