Table 6-7 Parameter set-up to reproduce Macro 3 on a Unidrive SP
Parameter
Value
OL CL
8.21 T24 digital I/O 1 source / destination Pr 1.46
8.25 T28 digital input 5 destination Pr 1.45
8.26 T29 digital input 6 destination Pr 1.42
8.31 T24 digital I/O 1 output select OFF (0)
8.39 T28 & T29 digital input auto selection disable On (1)
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 1.05
11.05 Define Pr 0.15 Pr 2.04
11.06 Define Pr 0.16 Pr 6.01
11.07 Define Pr 0.17 Pr 8.17
11.08 Define Pr 0.18 Pr 2.06
11.09 Define Pr 0.19 Pr 2.07
11.10 Define Pr 0.20 Pr 1.29
11.11 Define Pr 0.21 Pr 1.30
11.12 Define Pr 0.22 Pr 1.31
11.13 Define Pr 0.23 Pr 1.32
11.14 Define Pr 0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 1.21
11.16 Define Pr 0.26 Pr 1.22
11.17 Define Pr 0.27 Pr 1.23
11.18 Define Pr 0.28 Pr 1.24
11.19 Define Pr 0.29 Pr 0.00
11.20 Define Pr 0.30 Pr 0.00
