Control Techniques unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance
Feature look-
up table
Unidrive SP Advanced User Guide 345
Issue Number: 7 www.controltechniques.com
Table 6-11 Parameter set-up to reproduce Macro 5 on a Unidrive SP
Parameter
Value
OL CL
7.10 Analog input 1 destination Pr 0.00
7.14 Analog input 2 destination Pr 1.27
7.18 Analog input 3 destination Pr 1.28
8.26 T29 digital input 6 destination Pr 14.08
8.39
T28 and T29 digital input auto selection disable On (1)
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 0.00
11.05 Define Pr 0.15 Pr 7.11
11.06 Define Pr 0.16 Pr 7.15
11.07 Define Pr 0.17 Pr 7.01
11.08 Define Pr 0.18 Pr 7.02
11.09 Define Pr 0.19 Pr 7.03
11.10 Define Pr 0.20 Pr 14.10
11.11 Define Pr 0.21 Pr 14.11
11.12 Define Pr 0.22 Pr 14.12
11.13 Define Pr 0.23 Pr 14.13
11.14 Define Pr 0.24 Pr 14.14
11.15 Define Pr 0.25 Pr 14.15
11.16 Define Pr 0.26 Pr 1.27
11.17 Define Pr 0.27 Pr 1.28
11.18 Define Pr 0.28 Pr 7.12
11.19 Define Pr 0.29 Pr 7.16
11.20 Define Pr 0.30 Pr 14.09
14.02 Main reference source Pr 7.01
14.03 PID reference source Pr 1.27
14.04 PID feedback source Pr 1.28
14.16 PID output destination Pr 1.36
