Unidrive SP Advanced User Guide 349
Issue Number: 7 www.controltechniques.com
Table 6-13 Parameter set-up to reproduce Macro 6 on a Unidrive SP
Parameter
Value
OL CL
1.10 Bipolar select On (1)
2.04 Ramp mode FASt
2.22 Deceleration rate 2 1.0 2.0
8.39 T28 & T29 digital input auto selection disable On (1)
8.25 T28 digital input 5 destination Pr 6.35
8.26 T29 digital input 6 destination Pr 6.36
9.04 Logic function 1 source 1 Pr 6.35 Pr 0.00
9.05 Logic function 1 source 1 invert On (1) OFF (0)
9.06 Logic function 1 source 2 Pr 6.36 Pr 0.00
9.07 Logic function 1 source 2 invert On (1) OFF (0)
9.08 Logic function 1 output invert On (1) OFF (0)
9.10 Logic function 1 destination Pr 2.35 Pr 0.00
11.01 Define Pr 0.11 Pr 1.03
11.02 Define Pr 0.12 Pr 2.01
11.03 Define Pr 0.13 Pr 4.02
11.04 Define Pr 0.14 Pr 8.05
11.05 Define Pr 0.15 Pr 8.03
11.06 Define Pr 0.16 Pr 8.04
11.07 Define Pr 0.17 Pr 8.06
11.08 Define Pr 0.18 Pr 6.01
11.09 Define Pr 0.19 Pr 6.08
11.10 Define Pr 0.20 Pr 2.22 Pr 0.00
11.11 Define Pr 0.21 Pr 8.15
11.12 Define Pr 0.22 Pr 8.16
11.13 Define Pr 0.23 Pr 0.00
11.14 Define Pr 0.24 Pr 0.00
11.15 Define Pr 0.25 Pr 0.00
11.16 Define Pr 0.26 Pr 0.00
11.17 Define Pr 0.27 Pr 0.00
11.18 Define Pr 0.28 Pr 0.00
11.19 Define Pr 0.29 Pr 0.00
11.20 Define Pr 0.30 Pr 0.00
