132 • Operational Reference Nano Series GigE Vision Camera
Pulse on: Input 2 Event PulseOnInput2 Generate a pulse on the Input signal 2 event
Pulse on: Action 1 PulseOnAction1 Generate a pulse on the
GigEVision Action Command 1. (ver:1.03)
Pulse on: Action 2 PulseOnAction2 Generate a pulse on the
GigEVision Action Command 2. (ver:1.03)
Pulse on: Software
Command
PulseOnSoftwareCmd Generate a pulse on the Input of a Software
Command
Exposure Active ExposureActive Generate a signal that is active when the Exposure
is active. <from v1.01> (N/A for C4900 – 1.06)
Output Line Pulse Signal
Activation
outputLinePulseActivation Specifies the input line activation mode to trigger
the OutputLine pulse.
Beginner
Rising Edge RisingEdge Specifies that the trigger is considered valid on the
rising edge of the source signal.
Falling Edge FallingEdge Specifies that the trigger is considered valid on the
falling edge of the source signal.
Any Edge AnyEdge Specifies that the trigger is considered valid on the
falling or rising edge of the source signal.
Output Line Pulse Delay outputLinePulseDelay Sets the delay (in µs) before the output line pulse
signal. Applicable for the OutputLineSource
feature.
Beginner
DFNC
Output Line Pulse Duration outputLinePulseDuration Sets the width (duration) of the output line pulse in
microseconds.
Beginner
Output Line Value outputLineValue Sets the output state of the selected Line if the
outputLineSoftwareLatchControl = OFF.
OutputLineSource must be SoftwareControlled. If
the outputLineSoftwareLatchControl = Latch , the
state of the pin will change with the
outputLineSoftwareCmd command.
Beginner
DFNC
Active Active Sets the Output circuit to close
Inactive Inactive Sets the Output circuit to open
Output Line Software Latch
Control
outputLineSoftwareLatchControl When Off, the selected output line is set with the
value in Output Line Value.
Guru
Off Off Output pin state set by outputLineValue.
Latch Latch Output pin state set by outputLineSoftwareCmd.
Flash Zone Delay flashZoneDelay Returns the recommended output pulse delay,
corresponding to the delay of the last line exposure
start of a rolling shutter sensor, when the Output
Line Source = Pulse on Start of Exposure. (RO)
Guru
DFNC
Model C4900
Flash Zone Duration flashZoneDuration Returns the recommended output pulse duration
for controlling a flash device for the optimal flash
zone time. (RO)
Guru
DFNC
Output Line Software
Command
outputLineSoftwareCmd Writing a value of 1 in the bit field applies the
Latch value of the outputLineSoftwareLatchControl
and/or executes the PulseOnSoftwareCmd for any
output line programmed for software control. The
feature outputLineSoftwareCmd can take any
binary value and each bit set to 1 corresponds to a
Icommand for an Output. Note that Outputs are
numbered from 1 to N, therefore Bit 1 of
outputLineSoftwareCmd corresponds to Output1.
This is applicable to OutputLineSource = Pulse On:
where Software Cmd (for Pulse mode) or
OutputLineSource = SoftwareControlled and
OutputLineSoftwareLatchControl = Latch (for static
states).
Expert
DFNC
Line Pinout linePinAssociation Enumeration of the physical line (or pin) on the
device I/O connector. (RO)
Invisible
Pin5=Signal – Pin3=Gnd Pin5Signal_Pin3Gnd Pin 5 is the Input Signal and Pin 3 is the common
input Ground on the I/O connector.
Pin7=Signal – Pin3=Gnd Pin7Signal_Pin3Gnd Pin 7 is the Input Signal and Pin 3 is the common
input Ground on the I/O connector.
