144 • Operational Reference Nano Series GigE Vision Camera
Display Name Feature & Values Description
Device
Version
& View
Counter Selector counterSelector Selects the counter to configure.
Expert
Counter 1 Counter1 Select counter 1
Counter mode counterMode Selects the counter mode. The selected Counter is
either Active or Disabled. When Disabled, the Counter
can be configured.
Expert
DFNC
Off Off The selected Counter is Disabled
Active Active The selected Counter is Enabled
Counter Status counterStatus Returns the current state of the counter.
Expert
Counter Idle CounterIdle The counter is idle.
The counterStartSource feature is set to off.
Counter Trigger Wait CounterTriggerWait The counter is waiting for a start trigger.
Counter Active CounterActive The counter is counting for the specified duration.
Counter Completed CounterCompleted The counter reached the CounterDuration count.
Counter Overflow CounterOverflow The counter reached its maximum possible count.
Counter Start Source counterStartSource Select the counter start source. Counter increments
from 0 to the value of the counterDuration feature.
1.10
Expert
DFNC
Off Off Counter is stopped.
Acquisition Start AcquisitionStart Counter starts on the reception of the Acquisition
Start event.
Acquisition End AcquisitionEnd Counter starts on the reception of the Acquisition End
event.
Exposure Start ExposureStart Counter starts on the reception of the Exposure Start
event
Exposure End ExposureEnd Counter starts on the reception of the Exposure End
event.
Readout Start ReadoutStart Counter starts on the reception of the Readout Start
event.
Readout End ReadoutEnd Counter starts on the reception of the Readout End
event.
Frame Start FrameStart Counter starts on the reception of the Frame Start
event.
Valid Frame Trigger ValidFrameTrigger Counter starts on the reception of the Valid Frame
Trigger.
Rejected Frame Trigger InvalidFrameTrigger Counter starts on the reception of the Invalid Frame
Trigger.
Action 1 Action1 GigEVision Action Command 1. This is a broadcast
command that multiple devices can respond to
simultaneously. (1.03)
Action 2 Action2 GigEVision Action Command 2. This is a broadcast
command that multiple devices can respond to
simultaneously. (1.03)
Line 1 Line1 Counter starts on the specified transitions on Line 1
See Input Signals Electrical Specifications.
Line 2 Line2 Counter starts on the specified transitions on Line 2
Timer 1 End Timer1End Counter starts on the reception of the Timer 1 End
event.
Counter 1 End Counter1End Counter starts on the reception of the Counter 1 End
event.
Counter Start Line
Activation
counterStartLineActivation Selects the activation mode of the input line trigger
which starts the counter. This is only applicable when
the counterStartSource feature selects a physical
Line.
Expert
DFNC
