Dalsa Genie Nano Series User Manual

Nano Series GigE Vision Camera Operational Reference • 145
Rising Edge RisingEdge Starts counting on rising edge of the selected Line.
Falling Edge FallingEdge Starts counting on falling edge of the selected Line.
Any Edge AnyEdge Starts counting on the falling or rising edge of the
selected Line.
Counter Incremental
Source
counterIncrementalSource Select the event source which increments the
counter. The Event Control section provides details
and timing diagrams for the supported events.
1.00
Expert
DFNC
Off Off Counter is stopped.
Acquisition Start AcquisitionStart Counts the number of Acquisition Start events.
Acquisition End AcquisitionEnd Counts the number of Acquisition End events.
Exposure Start ExposureStart Counts the number of Exposure Start events.
ExposureEnd ExposureEnd Counts the number of Exposure End events.
Readout Start ReadoutStart Counts the number of Readout Start events.
Readout End ReadoutEnd Counts the number of Readout End events.
Frame Start FrameStart Counts the number of Frame Start events.
Valid Frame Trigger ValidFrameTrigger Counts the number of Valid Frame Triggers.
Rejected Frame(s)
Trigger
InvalidFrameTrigger Counts the number of Rejected Frame(s) Trigger.
MultiFrame End Trigger FrameBurstEnd Counts the number of multi-frame end triggers
Line 1 Line1 Counts the number of transitions on Line 1 (based on
the counterIncrementalLineActivation feature setting)
See Input Signals Electrical Specifications.
Line 2 Line2 Counts the number of transitions on Line 2 (based on
the counterIncrementalLineActivation feature setting)
Output 1 Line3 Counts the number of transitions of Output 1 (based
on the counterIncrementalLineActivation feature
setting)
Output 2 Line4 Counts the number of transitions of Output 2 (based
on the counterIncrementalLineActivation feature
setting)
Internal Clock InternalClock The counter increments on each microsecond tick of
the device internal Clock.
Timer 1 End Timer1End Counts the number of Timer 1 End events.
Counter Incremental Line
Activation
counterIncrementalLineActivation Selects the counter signal activation mode. The
counter increments on the specified signal edge or
level.
1.00
Expert
DFNC
Rising Edge RisingEdge Increment the counter on the rising edge of the
selected I/O Line.
Falling Edge FallingEdge Increment the counter on the falling edge of the
selected I/O Line.
Any Edge AnyEdge Increment the counter on the falling or rising edge of
the selected I/O Line.
Counter Duration counterDuration Sets the duration (or number of events) before the
CounterEnd event is generated.
1.00
Expert
DFNC
Counter Reset Source counterResetSource Selects the signal source to reset the counter. After a
reset the counter waits for the next countStartSource
signal or event.
1.10
Expert
DFNC
Reset Cmd Off Reset on reception of the Reset Icommand.
Acquisition Start AcquisitionStart Reset on reception of the Acquisition Start.
Acquisition End AcquisitionEnd Reset on reception of the AcquisitionEnd
Exposure Start ExposureStart Reset on reception of the Exposure Start event.
Exposure End ExposureEnd Reset on reception of the Exposure End event.
Readout Start ReadoutStart Reset the counter on the reception of the Readout
Start event.
Readout End ReadoutEnd Reset the counter on the reception of the Readout
End event.
Frame Trigger FrameStart Reset on reception of the Frame Trigger.
