146 • Operational Reference Nano Series GigE Vision Camera
Valid Frame Trigger ValidFrameTrigger Reset on reception of the Valid Frame Trigger.
Rejected Frame Trigger InvalidFrameTrigger Reset on reception of the Invalid Frame Trigger.
MultiFrame End Trigger FrameBurstEnd Reset on reception of the Frame Burst end.
Line 1 Line1 Reset counter on the specified transition on line 1.
See Input Signals Electrical Specifications.
Line 2 Line2 Reset counter on the specified transition on line 2.
Output 1 Line3 Counts the number of transitions of Output 1 (based
on the counterIncrementalLineActivation feature
setting).
Output 2 Line4 Counts the number of transitions of Output 2 (based
on the counterIncrementalLineActivation feature
setting).
Timer 1 End Timer1End Reset on reception of the Timer End.
Counter 1 End Counter1End Reset on the reception of the Counter end.
Counter Reset Input Line
Activation
counterResetLineActivation Specify the edge transition on the selected line that
will reset the selected counter.
Expert
Rising Edge RisingEdge Reset counter on rising edge of the selected signal.
Falling Edge FallingEdge Reset counter on falling edge of the selected signal.
Any Edge AnyEdge Reset counter on the falling or rising edge of the
selected signal
Counter Value counterValue Read the current value of the selected counter.
Expert
Counter Value At Reset counterValueAtReset Stores the counter value of the selected counter when
it was reset by a trigger or by an explicit Counter
Reset command.
Expert
DFNC
Counter Reset counterReset Resets the selected counter to zero. The counter
starts immediately after the reset. To temporarily
disable the counter, set the Counter Event Source
feature to Off.
Expert
DFNC
Timer Selector timerSelector Selects which timer to configure.
Expert
Timer 1 Timer1 Timer 1 selected
Timer Mode timerMode Select the Timer mode. The selected Timer is Active
or Disabled. When Disabled, the Timer can be
configured.
Expert
DFNC
Off Off The selected Timer is Disabled.
Active Active The selected Timer is Enabled.
Timer Status timerStatus Returns the current state of the timer.
Expert
Timer Idle TimerIdle The timer is idle. The CounterStartSource feature is
set to off.
Timer Trigger Wait TimerTriggerWait The timer is waiting for a start trigger.
Timer Active TimerActive The timer is counting for the specified duration.
Timer Completed TimerCompleted The timer reached the TimerDuration count.
Timer Start Source timerStartSource Select the trigger source to start the timer. The Event
Control section provides details and timing diagrams
for the supported events.
Expert
DFNC
TimerReset Cmd Off Starts with the reception of the TimerReset
Icommand.
Acquisition Start AcquisitionStart Start Timer on Acquisition Start event.
Acquisition End AcquisitionEnd Start Timer on Acquisition End event
Exposure Start ExposureStart Start Timer on Exposure Start event.
Exposure End ExposureEnd Start Timer on Exposure End event.
Readout Start ReadoutStart Start Timer on Readout Start event.
