Nano Series GigE Vision Camera Operational Reference • 153
8 Bits/Pixel
10 Bits/Pixel
12 Bits/Pixel
Bpp8
Bpp10
Bpp12
8 bits per pixel
10 bits per pixel
12 bits per pixel
LUT Index LUTIndex Selects the index (offset) of the coefficient to
access in the selected LUT.
Ver. 1.03
Guru
LUT Value LUTValue Returns the value at specified LUT index entry
of the LUT selected by the LUT Selector
feature.
Ver. 1.03
Guru
LUT Value All LUTValueAll Accesses all the LUT coefficients in a single
access without using individual LUT indices.
This feature accesses the LUT values in the
currently active LUT table set by the LUT
Current Active Set feature.
Ver. 1.03
Guru
Processing path bits per pixel processingPathBpp < >
Ver. 1.03
Invisible
DFNC
LUT Current Active Set lutCurrentActiveSet Specifies the current LUT to use.
< Invisible, DFNC >
Ver. 1.05
Invisible
DFNC
Luminance 1 Luminance1 Sets the current LUT as Luminance 1.
LUT RGB RGB Sets the current LUT as RGB.
