Dalsa Genie Nano Series User Manual

166 • Operational Reference Nano Series GigE Vision Camera
Cycling Preset Repeater cyclingPresetRepeater Specifies the required number of cycling preset increment
events (generated by the Cycling Preset Incremental
Source) to increment the index of the Cycling Preset
Current Active Set.
Ver. 1.01
DFNC
Expert
Cycling Preset Reset Source cyclingPresetResetSource Specifies the source that resets the currently active
preset. On reset the current preset index is set to 1.
Ver. 1.01
DFNC
Expert
Valid Frame Trigger ValidFrameTrigger Reset when a Valid Frame Triggers occurs.
Counter 1 End Counter1End Reset when counter 1 ends.
Acquisition End EndOfAcquisition Use End of Acquisition as the reset source. An End of
Acquisition occurs on acquisition stop.
Software Software Use a software command as the reset source.
Cycling Preset Reset Cmd cyclingPresetResetCmd Reset the position of the preset cycling to 1 and the count
to 0.
Ver. 1.01
DFNC
Guru
Cycling Preset Current Active
Set
cyclingPresetCurrentActiveSet Returns the index of the currently active cycling preset. Ver. 1.01
DFNC
Guru
Cycling Preset ROI Source cyclingPresetRoiPositionSource Specifies the source that cycles the ROI position
(availability is sensor dependent). < DFNC, Expert >
Note: Only on OnSemi Python sensor models
— Ver. 1.05
OnSemi
Python
In-FPGA FPGA The FPGA cycles the ROI position.
In-Sensor Sensor The sensor cycles the ROI position.
Features Activation Selector cP_FeaturesActivationSelector Selects the feature to control by the
cP_FeaturesActivationMode feature.
Ver. 1.01
DFNC
Expert
Exposure Time ExposureTime The cP_FeaturesActivationMode feature controls the
exposure time.
Exposure Delay ExposureDelay The cP_FeaturesActivationMode feature controls the
exposure delay.
ROI Position ROI_Position The cP_FeaturesActivationMode feature will control ROI
position.
Output Line3 OutputLine3Control The cP_FeaturesActivationMode feature controls the
output line 3.
Output Line4 OutputLine4Control The cP_FeaturesActivationMode feature controls the
output line 4.
Binning Horizontal BinningHorizontal The cP_FeaturesActivationMode controls the horizontal
binning.
Ver. 1.03
Binning Vertical BinningVertical The cP_FeaturesActivationMode controls the vertical
binning.
Ver. 1.03
Sensor Analog Gain SensorAnalogGain The cP_FeaturesActivationMode controls the sensor
analog gain.
Ver. 1.04
Preset Repeater PresetRepeater The cP_FeaturesActivationMode controls the preset
repeater count.
Ver. 1.04
