Nano Series GigE Vision Camera Operational Reference • 179
MonoPacked MonoPacked Pixel is monochrome and packed
Raw Bayer Raw Pixel is raw Bayer
BGR8 Packed BGR8Packed Pixel is BGR 24-bit 1.05
RGB Design
BGRA Packed BGRA8Packed Pixel is BGRA 32-bit 1.05
RGB Design
YUV422 Packed YUV422Packed Pixel is YUV422 16-bit UYVY 1.05
RGB Design
YUYV Packed YUYVPacked Pixel is YUV422 16-bit YUYV 1.05
RGB Design
Raw Bayer Packed RawPacked Pixel is raw Bayer Packed 1.08
RGB Design
Pixel Color Filter PixelColorFilter Indicates the type of color filter applied to the image. Invisible
None None No filter applied on the sensor.
Bayer GR BayerGR For BayerGR, the 2x2 mosaic alignment is GR/BG.
Bayer RG BayerRG For BayerRG, the 2x2 mosaic alignment is RG/GB.
Bayer GB BayerGB For BayerGB, the 2x2 mosaic alignment is GB/RG.
Bayer BG BayerBG For BayerBG, the 2x2 mosaic alignment is BG/GR.
