Dalsa Genie Nano Series User Manual

218 • Operational Reference Nano Series GigE Vision Camera
Locked Locked The servo is adjusting (synchronizing) to the
master clock.
Not Applicable NotApplicable The servo state is currently not applicable.
PTP Master Clock Identity ptpMasterClockId Port identity of the current best master. The clock
ID is an Extended Unique Identifier (EUI)-64 64-
bit ID, converted from the 48-bit MAC address, by
inserting 0xfffe at the middle of the MAC address.
1.03
Guru
DFNC
PTP Master Offset ptpMasterOffsetNs Dynamically returns the 64-bit value of the PTP
offset with the master. This value is the input for
clock corrections for the slave device clock servo
algorithms.
1.03
Guru
DFNC
PTP Port Last Event ptpPortLastEvent Logs the last PTP changed state event defining the
last current status.
1.03
Expert
DFNC
None None None
Power up Powerup Power up
Initialize Initialize Initialize
Designated Enabled DesignatedEnabled Designated Enabled
Designated Disabled DesignatedDisabled Designated Disabled
Fault Cleared FaultCleared Fault Cleared
Fault Detected FaultDetected Fault Detected
State Decision Event StateDecisionEvent State Decision Event
Qualification Timeout
Expires
QualificationTimeoutExpires Qualification Timeout Expires
Announce Receipt
Timeout Expires
AnnounceReceiptTimeoutExpires Announce Receipt Timeout Expires
Synchronization Fault SynchronizationFault Synchronization Fault
Master Clock Selected MasterClockSelected Master Clock Selected
Recommended State
Master
RS_Master Recommended State Master
Recommended State
Grand Master
RS_GrandMaster Recommended State Grand Master
Recommended State
Slave
RS_Slave Recommended State Slave
Recommended State
Passive
RS_Passive Recommended State Passive
PTP Transport Protocol ptpTransportProtocol Describes the PTP Transport Protocol used.
1.03
Expert
DFNC
PTP Servo Step Threshold
(in us)
ptpServoStepThreshold Specifies the servo step threshold (in us). When
the clock offset with the master exceeds the
threshold, the servo unlocks and offset adjustment
is started.
1.07
Expert
DFNC
Threshold_10 Threshold_10
Threshold_20 Threshold_20
Threshold_100 Threshold_100
Threshold_500 Threshold_500
Threshold_1000 Threshold_1000
Threshold_2000 Threshold_2000
Timestamp Modulo Event timestampModulo Specifies the additional interval between the
current timestamp tick and the event generated.
This interval has an 80ns accuracy. Note that the
value zero disables the event generator.
1.03
Expert
DFNC
Timestamp Modulo Event
Frequency
timestampModuloFrequency Returns the frequency of the timestamp Modulo
Event (in Hz).
1.03
Expert
DFNC
Timestamp Modulo Start
Time
timestampModuloStartTime Specifies the timestamp value that must be
exceeded by the incrementing timestamp counter
before the modulo event starts. This Feature is
also used for a “Future” Frame Acquisition.
1.03
Expert
DFNC
