Dalsa Genie Nano Series User Manual

314 • Addendums Nano Series GigE Vision Camera
Sensor Row
pix0 pix1
Pixel Pair 1
even odd
pix2 pix3
Pixel Pair 2
even odd
pix4 pix5
Pixel Pair 3
even odd
pix6 pix7
Pixel Pair 4
even odd
Pixel Data from last pixel
in previous row
• When a row’s last pixel pair has both even and odd pixels marked as bad, the even pixel is
replaced by preceding odd pixel and the odd pixel is replaced by the following even pixel
which is the following row’s first pixel (even if it is also marked as a bad pixel).
Sensor Row
pix0 pix1
Pixel Pair
even odd
pix(N-3) pix(N-2)
Pixel Pair
even odd
pix(N-1) pix(N)
Last Pixel Pair in Row
even odd
Pixel from next Row
When the sensor’s last row’s last pixel pair has both even and odd pixels marked as bad, the even
pixel is replaced by preceding odd pixel and the bad odd pixel is replaced by indeterminate data in
the following memory location.
LAST Sensor Row
pix0 pix1
Pixel Pair
even odd
pix(N-3) pix(N-2)
Pixel Pair
even odd
pix(N-1)
pix(N)
Last Pixel Pair in Sensor
even odd
Indeterminate Data
