Datalogic Magellan 8500Xt

E-4 Magellan
TM
8500Xt Scanner
RS-232 Ignore Host
Commands
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
RS-232 TTL
0 (normal
RS-232)
0 (normal
RS-232)
RS-232 TTL Invert 0 (disable) 0 (disable)
RS-232 Beep on
ASCII BEL
0 (disable) 0 (disable) 0 (disable)
RS-232 Beep After
Weigh
1 (enable) 1 (enable) 0 (disable) 1 (enable)
RS-232 Beep on Not
on File
1 (enable) 1 (enable) 1 (enable) 1 (enable)
RS-232 ACK NAK
Enable
0 (disable) 0 (disable) 0 (disable)
RS-232 ACK Charac-
ter
6 (ACK) 6 (ACK) 6 (ACK)
RS-232 NAK Charac-
ter
21 (NAK) 21 (NAK) 21 (NAK)
RS-232 Retry on
ACK NAK Timeout
1 (enable) 1 (enable) 1 (enable)
RS-232 ACK NAK
Timeout Value
1 (200ms) 1 (200ms) 1 (200ms)
RS-232 ACK NAK
Retry Count
3 resets 3 resets 3 resets
RS-232 ACK NAK
Error Handling
0 (ignore
errors)
0 (ignore
errors)
0 (ignore
errors)
RS-232 Label ID
Control
1 (enable
as prefix)
1 (enable
as prefix)
1 (enable
as prefix)
1 (enable
as prefix)
Single Cable RS-232
Scanner Only Proto-
col
0 (scan-
ner-scale)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 OEM USB
