Datalogic Magellan 8500Xt

Product Reference Guide E-5
Single Cable RS-232
RTS CTS Selection
Option 5
Single Cable RS-232
Use BCC
0 (disable)
Single Cable RS-232
Use ACK/NAK
0 (disable)
Single Cable RS-232
Use STX
1 (enable)
Set Single Cable RS-
232 STX Character
83 (S)
Single Cable RS-232
Use ETX
1 (enable)
Set Single Cable RS-
232 ETX Character
13 (CR)
Single Cable RS-232
Datalogic Extensions
0 (std
protocol)
UPC-A Enable 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
UPC-A Number Sys-
tem Character Trans-
mission
0 (disable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
UPC-A Check Char-
acter Transmission
1 (enable) 1 (enable) 1 (enable) 0 (disable) 1 (enable) 1 (enable)
Expand UPC-A to
EAN-13
0 (disable) 0 (disable) 1 (enable) 0 (disable) 0 (disable) 0 (disable)
UPC/EAN AIM ID 0 (disable) 0 (disable) 0 (disable)
UPC-A Label ID 4100("A") 4100("A") 4100("A") 4100("A")
UPC-A 2-Digit Sup-
plemental Label ID
4100("A") 4100("A") 4100("A") 4100("A")
UPC-A 5-Digit Sup-
plemental Label ID
4100("A") 4100("A") 4100("A") 4100("A")
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 OEM USB
