Datalogic Magellan 8500Xt

E-10 Magellan
TM
8500Xt Scanner
Code 32 Start Stop
Character Transmis-
sion
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Code 32 Check Char-
acter Transmission
1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
Code 32 Label ID 4100("A") 4100("A") 4100("A") 4100("A")
Code 128 Enable 1 (enable) 1 (enable) 0 (disable) 1 (enable) 1 (enable) 1 (enable)
Code 128 Transmit
Function Characters
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Convert Code128 to
Code 39
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Code 128 AIM ID 0 (disable) 0 (disable) 0 (disable)
Code 128 Label ID 2300 ("#") 2300 ("#") 4B00 ("K")
4233
("B3")
Code 128 Length
Control
0
(variable)
0
(variable)
0
(variable)
0
(variable)
0
(variable)
0
(variable)
Code 128 Length 1
8 Fixed
2 Min
8 Fixed
2 Min
8 Fixed
2 Min
8 Fixed
2 Min
8 Fixed
2 Min
8 Fixed
2 Min
Code 128 Length 2
14 Fixed
80 Max
14 Fixed
80 Max
14 Fixed
80 Max
14 Fixed
80 Max
14 Fixed
80 Max
14 Fixed
80 Max
Code 128 Stitching 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
EAN-128 Enable 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
EAN 128 AIM ID 1 (enable) 1 (enable) 0 (disable)
EAN 128 Label ID 0000 ("") 0000 ("") 5000 ("P") 0000 ("")
Interleaved 2 of 5 (I 2
OF 5) Enable
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
I 2 of 5 Check Char-
acter Calculation
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 OEM USB
