Datalogic Magellan 8500Xt

Product Reference Guide E-11
I 2 of 5 Check Char-
acter Transmission
1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
I 2 of 5 AIM ID 0 (disable) 0 (disable) 0 (disable)
I 2 of 5 Label ID 6900 ("i") 6900 ("i") 4900 ("I")
4232
("B2")
I 2 of 5 Length Con-
trol
0
(variable)
0
(variable)
0
(variable)
0
(variable)
0
(variable)
0
(variable)
I 2 of 5 Length 1
10 Fixed
6 Min
10 Fixed
6 Min
10 Fixed
6 Min
10 Fixed
6 Min
10 Fixed
6 Min
10 Fixed
6 Min
I 2 of 5 Length 2
0 Fixed
50 Max
0 Fixed
50 Max
0 Fixed
50 Max
0 Fixed
50 Max
0 Fixed
50 Max
0 Fixed
50 Max
I 2 of 5 Stitching 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Codabar Enable 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Codabar Start Stop
Character Transmis-
sion
0 (disable) 0 (disable) 1 (enable) 0 (disable) 0 (disable) 0 (disable)
Codabar Start Stop
Character Set
3 (abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
3 (abcd/
abcd)
Codabar Start Stop
Character Match
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Codabar Check
Character Calculation
0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable) 0 (disable)
Codabar Check
Character Transmis-
sion
1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable) 1 (enable)
Codabar AIM ID 0 (disable) 0 (disable) 0 (disable)
Codabar Label ID 2500 ("%") 2500 ("%") 4E00 ("N") 2500 ("%")
Codabar Length Con-
trol
0
(variable)
0
(variable)
0
(variable)
0
(variable)
0
(variable)
0
(variable)
Aux RS-232
Wincor-
Nixdorf
Single
Cable
IBM 17 OEM USB
