Datalogic Magellan 8500Xt

Product Reference Guide 2-33
interface cable while securing the Remote Scale Display to the
checkstand.
Figure 2-20. Model 960RD: Remote Scale Display Components
48 - 60"
(122 - 152cm)
36"
(91cm)
11.5"
(29cm)
24"
(61cm)
(optional
cable
routing)
Cable end
after
rubberband
is removed.
Display Head
Display Base
Display Stalk
Cable
Connector
Interface
Cable
Mounting
Example
Figure 2-21. Model 960RD: Remote Scale Short Base Display Mounting Template
F RONT
3 3/8" (8.57 cm)
3/4"
(1.9 cm)
4 1/2" (11.4 cm)
1 1/2"
(3.8 cm)
