Gasketed Models
1. Remove the All Weighs™ Platter from the scanner as shown in
Figure 3-3.
2. Turn the platter upside down on a clean, dry surface and remove
the two screws and two nuts shown in
Figure 3-6a. Retain all
screws and nuts for later reinstallation.
3. Lift the edge of the retainer shown in Figure 3-6b and remove it
from the assembly.
4. Take note of how the gasket is seated, then gently peel it away
from the assembly as shown in
Figure 3-6c. Retain the gasket for
reinstallation.
5. The window can now be removed (see Figure 3-6d). Carefully dis-
pose of any damaged glass.
6. While carefully holding it by its edges, tilt a new horizontal win-
dow fully into position as shown in Figure 3-6d.
7. Fit the gasket into its channel as shown in Figure 3-6c and press
around its entire perimeter to ensure it is fully seated.
8. Reinstall the retainer in the orientation shown in Figure 3-6b,
aligning both holes with their studs.
9. Secure the retainer using the original two screws and two nuts as
shown in
Figure 3-6a.
10. Clean both sides of the new horizontal window using a paper
towel or lint free cleaning tissues dampened with a mild, water-
based glass cleaner. DO NOT use abrasive cleaners or pads.
Reinstall the platter. Gasketed horizontal window replacement is now
complete.
