Table 90. MIB Objects for Fetching Dynamic MAC Entries in the Forwarding Database
MIB Object OID MIB Description
dot1dTpFdbTable .1.3.6.1.2.1.17.4.3 Q-BRIDGE MIB List the learned unicast
MAC addresses on the
default VLAN.
dot1qTpFdbTable .1.3.6.1.2.1.17.7.1.2. 2 Q-BRIDGE MIB List the learned unicast
MAC addresses on non-
default VLANs.
dot3aCurAggFdb Table .1.3.6.1.4.1.6027.3.2. 1.1.5 F10-LINK-
AGGREGATION -MIB
List the learned MAC
addresses of aggregated
links (LAG).
In the following example, R1 has one dynamic MAC address, learned off of port TenGigabitEthernet 1/21,
which a member of the default VLAN, VLAN 1. The SNMP walk returns the values for dot1dTpFdbAddress,
dot1dTpFdbPort, and dot1dTpFdbStatus.
Each object comprises an OID concatenated with an instance number. In the case of these objects, the
instance number is the decimal equivalent of the MAC address; derive the instance number by converting
each hex pair to its decimal equivalent. For example, the decimal equivalent of E8 is 232, and so the instance
number for MAC address 00:01:e8:06:95:ac is.0.1.232.6.149.172.
The value of dot1dTpFdbPort is the port number of the port off which the system learns the MAC address. In
this case, of TenGigabitEthernet 1/21, the manager returns the integer 118.
Example of Fetching MAC Addresses Learned on the Default VLAN Using SNMP
----------------MAC Addresses on Force10 System------------------
Dell#show mac-address-table
VlanId Mac Address Type Interface State
1 00:01:e8:06:95:ac Dynamic Te 1/21 Active
----------------Query from Management Station----------------------
>snmpwalk -v 2c -c techpubs 10.11.131.162 .1.3.6.1.2.1.17.4.3.1
SNMPv2-SMI::mib-2.17.4.3.1.1.0.1.232.6.149.172 = Hex-STRING: 00 01 E8 06 95 AC
Example of Fetching MAC Addresses Learned on a Non-default VLAN Using SNMP
In the following example, TenGigabitEthernet 1/21 is moved to VLAN 1000, a non-default VLAN. To fetch the
MAC addresses learned on non-default VLANs, use the object dot1qTpFdbTable. The instance number is the
VLAN number concatenated with the decimal conversion of the MAC address.
---------------MAC Addresses on Force10 System------------
Dell#show mac-address-table
VlanId Mac Address Type Interface State
1000 00:01:e8:06:95:ac Dynamic Te 1/21 Active
---------------Query from Management Station----------------
>snmpwalk -v 2c -c techpubs 10.11.131.162 .1.3.6.1.2.1.17.7.1.2.2.1
Example of Fetching MAC Addresses Learned on a Port-Channel Using SNMP
Use dot3aCurAggFdbTable to fetch the learned MAC address of a port-channel. The instance number is the
decimal conversion of the MAC address concatenated with the port-channel number.
--------------MAC Addresses on Force10 System-------------------
Dell(conf)#do show mac-address-table
VlanId Mac Address Type Interface State
Simple Network Management Protocol (SNMP) 1005
