Dell S4048T User Manual

Table 82. Drop Eligibility Behavior
Ingress Egress DEI Disabled DEI Enabled
Normal Port Normal Port Retain CFI Set CFI to 0.
Trunk Port Trunk Port Retain inner tag CFI Retain inner tag CFI.
Retain outer tag CFI Set outer tag CFI to 0.
Access Port Trunk Port Retain inner tag CFI Retain inner tag CFI
Set outer tag CFI to 0 Set outer tag CFI to 0
To enable drop eligibility globally, use the following command.
• Make packets eligible for dropping based on their DEI value.
CONFIGURATION mode
dei enable
By default, packets are colored green, and DEI is marked 0 on egress.
Honoring the Incoming DEI Value
To honor the incoming DEI value, you must explicitly map the DEI bit to an Dell Networking OS drop
precedence.
Precedence can have one of three colors.
Precedence
Description
Green High-priority packets that are the least preferred to be dropped.
Yellow Lower-priority packets that are treated as best-effort.
Red Lowest-priority packets that are always dropped (regardless of congestion status).
• Honor the incoming DEI value by mapping it to an Dell Networking OS drop precedence.
INTERFACE mode
dei honor {0 | 1} {green | red | yellow}
You may enter the command once for 0 and once for 1.
Packets with an unmapped DEI value are colored green.
Example of Viewing DEI-Honoring Configuration
To display the DEI-honoring configuration, use the show interface dei-honor [interface slot/
port
[/subport]] in EXEC Privilege mode.
Dell#show interface dei-honor
Default Drop precedence: Green
Interface CFI/DEI Drop precedence
---------------------------------------
Te 1/1 0 Green
Te 1/1 1 Yellow
Service Provider Bridging 958

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
