dot1p Queue Number
2 0
3 1
4 2
5 3
6 3
7 3
• Change the priority of incoming traffic on the interface.
dot1p-priority
Example of Configuring a dot1p Priority on an Interface
Dell#configure terminal
Dell(conf)#interface tengigabitethernet 1/1
Dell(conf-if-te-1/1)#switchport
Dell(conf-if-te-1/1)#dot1p-priority 1
Dell(conf-if-te-1/1)#end
Honoring dot1p Priorities on Ingress Traffic
By default, Dell Networking OS does not honor dot1p priorities on ingress traffic.
You can configure this feature on physical interfaces and port-channels, but you cannot configure it on
individual interfaces in a port channel.
You can configure service-class dynamic dot1p from CONFIGURATION mode, which applies the
configuration to all interfaces. A CONFIGURATION mode service-class dynamic dot1p entry supersedes any
INTERFACE entries. For more information, refer to Mapping dot1p Values to Service Queues.
NOTE
: You cannot configure service-policy input and service-class dynamic dot1p on the
same interface.
• Honor dot1p priorities on ingress traffic.
INTERFACE mode
service-class dynamic dot1p
Example of Configuring an Interface to Honor dot1p Priorities on Ingress Traffic
Dell#configure terminal
Dell(conf)#interface tengigabitethernet 1/1
Dell(conf-if-te-1/1)#service-class dynamic dot1p
Dell(conf-if-te-1/1)#end
Priority-Tagged Frames on the Default VLAN
Priority-tagged frames are 802.1Q tagged frames with VLAN ID 0. For VLAN classification, these packets are
treated as untagged. However, the dot1p value is still honored when you configure service-class
dynamic dot1p
or trust dot1p.
When priority-tagged frames ingress an untagged port or hybrid port, the frames are classified to the default
VLAN of the port and to a queue according to their dot1p priority if you configure service-class dynamic
Quality of Service (QoS) 836
