Dell S4048T - Configuring Layer 2 (Data Link) Mode; Configuring Layer 2 (Interface) Mode

Table 41. Layer Modes
Type of Interface Possible Modes Requires Creation Default State
10 Gigabit Ethernet and
40 Gigabit Ethernet
Layer 2
Layer 3
No Shutdown (disabled)
Management N/A No Shutdown (disabled)
Loopback Layer 3 Yes No shutdown (enabled)
Null interface N/A No Enabled
Port Channel
Layer 2
Layer 3
Yes Shutdown (disabled)
VLAN
Layer 2
Layer 3
Yes, except for the
default VLAN.
No shutdown (active for
Layer 2)
Shutdown (disabled for
Layer 3 )
Configuring Layer 2 (Data Link) Mode
Do not configure switching or Layer 2 protocols such as spanning tree protocol (STP) on an interface unless
the interface has been set to Layer 2 mode.
To set Layer 2 data transmissions through an individual interface, use the following command.
• Enable Layer 2 data transmissions through an individual interface.
INTERFACE mode
switchport
Example of a Basic Layer 2 Interface Configuration
Dell(conf-if)#show config
!
interface Port-channel 1
no ip address
switchport
no shutdown
Dell(conf-if)#
Configuring Layer 2 (Interface) Mode
To configure an interface in Layer 2 mode, use the following commands.
• Enable the interface.
INTERFACE mode
no shutdown
Interfaces 457
