Dell S4048T User Manual

Table 98. Configuring VRRP on a VRF
Task Command Syntax Command Mode
Create VRF
ip vrf vrf1
CONFIGURATION
Assign the VRF to an
interface
ip vrf forwarding vrf1
VRF CONFIGURATION
Assign an IP address to
the interface
ip address 10.1.1.1 /24
no shutdown
Configure the VRRP
group and virtual IP
address
vrrp-group 10
virtual-address 10.1.1.100
show config
-----------------------------
!
interface TenGigabitEthernet 1/13
ip vrf forwarding vrf1
ip address 10.1.1.1/24
!
vrrp-group 10
virtual-address 10.1.1.100
no shutdown
View VRRP command
output for the VRF vrf1
show vrrp vrf vrf1
------------------
TenGigabitEthernet 1/13, IPv4
VRID: 10, Version: 2, Net:
10.1.1.1
VRF: 2 vrf1
State: Master, Priority: 100,
Master: 10.1.1.1 (local)
Hold Down: 0 sec, Preempt: TRUE,
AdvInt: 1 sec
Adv rcvd: 0, Bad pkts rcvd: 0,
Adv sent: 43, Gratuitous ARP
sent: 0
Virtual MAC address:
00:00:5e:00:01:0a
Virtual IP address:
10.1.1.100
Authentication: (none)
Configuring Management VRF
You can assign a management interface to a management VRF.
1 Create a management VRF.
CONFIGURATION
ip vrf management
2 Assign a management port to a management VRF.
VRF MODE
interface management
Virtual Routing and Forwarding (VRF) 1193

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
