Set Auto-Negotiation Options
The negotiation auto command provides a mode option for configuring an individual port to forced
master/ forced slave once auto-negotiation is enabled.
CAUTION: Ensure that only one end of the node is configured as forced-master and the other is
configured as forced-slave. If both are configured the same (that is, both as forced-master or both as
forced-slave), the show interface command flaps between an auto-neg-error and forced-master/
slave states.
Example of the negotiation auto Command
Dell(conf)# int tengigabitethernet 1/1
Dell(conf-if-te-1/1)#neg auto
Dell(conf-if-te-1/1-autoneg)# ?
end Exit from configuration mode
exit Exit from autoneg configuration mode
mode Specify autoneg mode
no Negate a command or set its defaults
show Show autoneg configuration information
Dell(conf-if-te-1/1-autoneg)#mode ?
forced-master Force port to master mode
forced-slave Force port to slave mode
Dell(conf-if-te-1/1-autoneg)#
For details about the speed, duplex, and negotiation auto commands, refer to the Interfaces chapter of
the
Dell Networking OS Command Reference Guide.
Adjusting the Keepalive Timer
To change the time interval between keepalive messages on the interfaces, use the keepalive command.
The interface sends keepalive messages to itself to test network connectivity on the interface.
To change the default time interval between keepalive messages, use the following command.
• Change the default interval between keepalive messages.
INTERFACE mode
keepalive [seconds]
• View the new setting.
INTERFACE mode
show config
View Advanced Interface Information
The following options have been implemented for the show [ip | running-config] interfaces
commands for (only) stack-unit interfaces.
When you use the configured keyword, only interfaces that have non-default configurations are displayed.
Dummy stack-unit interfaces (created with the stack-unit command) are treated like any other physical
interface.
Interfaces 490
