Dell S4048T User Manual

Storm Control
Storm control allows you to control unknown-unicast, muticast, and broadcast traffic on Layer 2 and Layer 3
physical interfaces.
Dell Networking Operating System (OS) Behavior: Dell Networking OS supports unknown-unicast, muticast,
and broadcast control for Layer 2 and Layer 3 traffic.
Dell Networking OS Behavior: The minimum number of packets per second (PPS) that storm control can
limit on the device is two.
To view the storm control broadcast configuration show storm-control broadcast | multicast |
unknown-unicast | pfc-llfc
[interface] command.
EXEC Privilege
To view the storm control multicast configuration, use the show storm-control broadcast |
multicast | unknown-unicast | pfc-llfc [interface] command.
EXEC Privilege
Example:
Dell#show storm-control multicast Tengigabitethernet 1/1
Multicast storm control configuration
Interface Direction Packets/Second
-----------------------------------------
Te 1/1 Ingress 5
Dell#
To display the storm control unknown-unicast configuration, use the show storm-control unknown-
unicast [interface] command.
EXEC Privilege
Configure Storm Control
Storm control is supported in INTERFACE mode and CONFIGURATION mode.
53
Storm Control 1041

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
