Configure Egress ACLs
Egress ACLs are applied to line cards and affect the traffic leaving the system. Configuring egress ACLs onto
physical interfaces protects the system infrastructure from attack — malicious and incidental — by explicitly
allowing only authorized traffic. These system-wide ACLs eliminate the need to apply ACLs onto each
interface and achieves the same results. By localizing target traffic, it is a simpler implementation.
To restrict egress traffic, use an egress ACL. For example, when a denial of service (DOS) attack traffic is
isolated to a specific interface, you can apply an egress ACL to block the flow from the exiting the box, thus
protecting downstream devices.
To create an egress ACL, use the ip access-group command in EXEC Privilege mode. The example shows
viewing the configuration, applying rules to the newly created access group, and viewing the access list.
NOTE: VRF based ACL configurations are not supported on the egress traffic.
Example of Applying ACL Rules to Egress Traffic and Viewing ACL Configuration
To specify ingress, use the out keyword. Begin applying rules to the ACL with the ip access-list
extended
abcd command. To view the access-list, use the show command.
Dell(conf)#interface TenGigabitEthernet 1/1
Dell(conf-if-te-1/1)#ip access-group abcd out
Dell(conf-if-te-1/1)#show config
!
TenGigabitEthernet 1/1
no ip address
ip access-group abcd out
no shutdown
Dell(conf-if-te-1/1)#end
Dell#configure terminal
Dell(conf)#
ip access-list extended abcd
Dell(config-ext-nacl)#permit tcp any any
Dell(config-ext-nacl)#deny icmp any any
Dell(config-ext-nacl)#permit 1.1.1.2
Dell(config-ext-nacl)#end
Dell#
show ip accounting access-list
!
Extended Ingress IP access list abcd on tengigabitethernet 0/0
seq 5 permit tcp any any
seq 10 deny icmp any any
seq 15 permit 1.1.1.2
Dell#configure terminal
Dell(conf)#interface te 1/2
Dell(conf-if-te-1/2)#ip vrf forwarding blue
Dell(conf-if-te-1/2)#show config
!
interface TenGigabitEthernet 1/2
ip vrf forwarding blue
no ip address
shutdown
Dell(conf-if-te-1/2)#
Dell(conf-if-te-1/2)#
Dell(conf-if-te-1/2)#end
Dell#
Access Control Lists (ACLs) 158

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
