Control Plane Policing (CoPP)
Control plane policing (CoPP) uses access control list (ACL) rules and quality of service (QoS) policies to
create filters for a system’s control plane. That filter prevents traffic not specifically identified as legitimate
from reaching the system control plane, rate-limits, traffic to an acceptable level.
CoPP increases security on the system by protecting the routing processor from unnecessary or DoS traffic,
giving priority to important control plane and management traffic. CoPP uses a dedicated control plane
configuration through the ACL and QoS command line interfaces (CLIs) to provide filtering and rate-limiting
capabilities for the control plane packets.
12
Control Plane Policing (CoPP) 281

Dell S4048T Specifications

General

Switching Capacity	1.44 Tbps
Rack Units	1U
Form Factor	Rack-mountable
Power Device	Internal power supply
Power Redundancy	Optional
Product Type	Switch
Jumbo Frame Support	Yes
Routing Protocol	OSPF, BGP, RIP, VRRP, PIM-SM, IGMP
Remote Management Protocol	SNMP, RMON, Telnet, SSH
Features	Quality of Service (QoS), Jumbo Frames Support, Virtual Route Redundancy Protocol (VRRP), VLAN support, sFlow, Multiple Spanning Tree Protocol (MSTP), Rapid Spanning Tree Protocol (RSTP), IPv6 support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae
Dimensions (W x D x H)	17.3 in x 16 in x 1.7 in
Operating Temperature	0°C to 40 °C
Operating Humidity	10% to 90% (non-condensing)
