3 0% ETS
4 0% ETS
5 0% ETS
6 0% ETS
7 0% ETS
Priority# Bandwidth TSA
0 13% ETS
1 13% ETS
2 13% ETS
3 13% ETS
4 12% ETS
5 12% ETS
6 12% ETS
7 12% ETS
Oper status is init
Conf TLV Tx Status is disabled
Traffic Class TLV Tx Status is disabled
0 Input Conf TLV Pkts, 0 Output Conf TLV Pkts, 0 Error Conf TLV Pkts
0 Input Traffic Class TLV Pkts, 0 Output Traffic Class TLV Pkts, 0 Error Traffic
Class TLV
Pkts
The following table describes the show interface ets detail command fields.
Table 23. show interface ets detail Command Description
Field Description
Interface Interface type with stack-unit and port number.
Maximum Supported TC Group Maximum number of priority groups supported.
Number of Traffic Classes Number of 802.1p priorities currently configured.
Admin mode ETS mode: on or off.
Admin Parameters ETS configuration on local port, including priority
groups, assigned dot1p priorities, and bandwidth
allocation.
Remote Parameters ETS configuration on remote peer port, including
Admin mode (enabled if a valid TLV was received or
disabled), priority groups, assigned dot1p priorities,
and bandwidth allocation. If the ETS Admin mode is
enabled on the remote port for DCBx exchange, the
Willing bit received in ETS TLVs from the remote peer
is included.
Local Parameters ETS configuration on local port, including Admin
mode (enabled when a valid TLV is received from a
peer), priority groups, assigned dot1p priorities, and
bandwidth allocation.
Operational status (local port) Port state for current operational ETS configuration:
• Init: Local ETS configuration parameters were
exchanged with peer.
• Recommend: Remote ETS configuration
parameters were received from peer.
Data Center Bridging (DCB) 333
