EcmpFlowBasedHashingAlgo- crc16
EcmpAlgo- crc32MSB LagAlgo- crc32LSB HgAlgo- crc16
Figure 41. After Polarization Effect
Traffic flow after enabling flow-based hashing
When the flow-based hashing is enabled at all the nodes in the multi-tier network, traffic distribution is
balanced at all tiers of the network nullifying the polarization effect. Traffic occurs by the randomness for the
flow-based hashing algorithm across multiple nodes in a given network.
Equal Cost Multi-Path (ECMP) 376
