Figure 112. Dell Networking QoS Architecture

Topics:

• Implementation Information

• Port-Based QoS Configurations

• Policy-Based QoS Configurations

• DSCP Color Maps

• Enabling QoS Rate Adjustment

• Enabling Strict-Priority Queueing

• Weighted Random Early Detection

• Pre-Calculating Available QoS CAM Space

• Configuring Weights and ECN for WRED

• Configuring WRED and ECN Attributes

• Guidelines for Configuring ECN for Classifying and Color-Marking Packets

Quality of Service (QoS) 834
