7.7 Main menu
If the [access code] is enabled , please note the following:
Ä
Chapter 7.7 ‘Main menu’ on page 73.
7.7.1 Open the main menu
Fig. 26: Calling up the main menu without an access code
1.
[Open main menu] by pressing the [Menu button] .
ð
The screen changes to the [Open main menu].
2. Use the [scrollbar] on the right-hand side of the screen to scroll to the required
setting and select it.
3.
Press the button to exit the [Main menu] again. The pump switches back to the
operation screen.
The following menu items can be accessed:
n Metering mode:
Ä
Chapter 7.8 ‘Metering mode’ on page 74
n
Operating mode:
Ä
Chapter 7.9 ‘Operating Mode’ on page 78
n
Configuration:
Ä
Chapter 7.10 ‘Overview - Configuration’ on page 92
n
Calibration:
Ä
Chapter 7.11 ‘Calibration’ on page 126
n
Operating data:
Ä
Chapter 7.12 ‘Operating data’ on page 128
n
Info:
Ä
Chapter 7.13 ‘Info’ on page 129
Control / Software
73 417102276 Rev. 5-02.2020
