9.6.1.1 [Metering mode] [V
-variable]
4
5
6
7
8
9
Fig. 89: Metering mode: “V-variable”
[Metering mode] - [V-variable] - setting:
1.
[Call up the main menu] by pressing the [Menu button] :
Ä Chapter 7.7 ‘Main menu’ on page 73.
2.
[select Configuration] :
Ä Chapter 7.10 ‘Overview - Configuration’ on page 92
3. [select Metering mode] .
ð
Screen switches to [Metering mode].
4. [Select Metering mode] - [V
-variable] .
5.
[ Click Next] to save the setting.
ð
The screen switches to the setting for ‘Capacity in L
’.
6. ‘Set the Capacity in L
’ in the place before the decimal point using the scrollbar.
7. Select the field for entering the value after the decimal point.
ð
The colour changes to dark blue, which indicates that the field is ready for input.
8. ‘Set the Capacity in L
’ in the place after the decimal point using the scrollbar.
9.
Pressing the button saves the setting.
ð
The screen switches to the overview for the [Metering mode].
10.
Press the button again to return to the [Main menu].
11.
Press the button.
ð
The screen switches back to the [operating display] .
Operation
148417102276 Rev. 5-02.2020
