The construction has been chosen in such a way that it is very easy to switch between the
‘EcoPro’ and ‘EcoAdd
’ control units.
In addition, the control panels can be rotated variably on the housing see:
Ä
Chapter 13.1.1 ‘Rotating the control unit’ on page 176.
On the supplied mounting plate, the pump can be fastened
without a tool both for table-
top mounting and wall mounting. For further info, see
Ä
Chapter 6.2 ‘Assembly variants’
on page 44.
CAUTION!
The use of a suction pipe with an empty signal provision and dirt trap from
our accessory programme is highly recommended to protect the metering
system. The empty signal system causes the pump to cut of
f if the medium
in the container drops below a certain level.
The pump is available in a number of variants:
n The design including complete software control via an operator panel is known as
‘EcoAdd
’ .
n By an extension with an additional Bluetooth PCB (
Ä
Chapter 13.2 ‘Upgrade: with
Bluetooth interface’ on page 178), it can be controlled and assessed with the
smartphone app ‘Ecolab EcoAPP’ .
4.1 Equipment features - ‘EcoAdd’
n
button: On/Off button
n Viscosity: 4 viscosity modes (standard , medium , low , variable )
n Operating modes: 5 operating modes (Manual, Pulse, Power, Timer, Batch)
n Display: Touch display
n Setting range: 1:100
n
Data exchange: USB port
n Inputs:
–
Electrical connection
– Enable signal
– Pulse input
– Power
– Charge
– Level (fill level)
– Flow
– Diaphragm breakage monitor
– USB input
n
Outputs:
–
Stroke signal
– Alarm
– CAN bus system
– USB output
Function description
37 417102276 Rev. 5-02.2020
