14 Technical specifications
14.1
Packaging
Data Value Unit
Packaging size (L x W x H) 395 x 290 x 360 mm
Weight (depending on pump design) 3,5 - 6 kg
Due to the low weight, no special lifting gear is required during transport.
14.2 Equipment marking / Rating plate
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Fig. 108: Rating plate
1 QR code for maintenance
2 CE mark
3 Disposal regulation:
The product may not be disposed of in the household
waste!
4 Protection class Marking Type 2
5 Eurasian Conformity
6 Bar code with the annual production code
7 Manufacturer's address
8 Annual production code
9 Material pairings of the pump
10 Power consumption
11 Voltage specification [V/Hz]
12 Q = Litre capacity [l/h]; p= Pressure [MPa]
13 Order number
14 Device type
15 Equipment designation
16 Barcode with order number
17 TÜV & UL Certification
Technical specifications
181 417102276 Rev. 5-02.2020
