8.1 Initial start-up
1. Install the mounting plate and pump in the required location and installation scenario.
Ä
Chapter 6 ‘Mounting and installation’ on page 42
2. Make the hydraulic connections.
Ä
Chapter 6.3 ‘Hydraulic Installation’ on page 47
3. If necessary
, make the electrical connections for signal inputs.
Ä
Chapter 6.4 ‘Electrical installation’ on page 56
4. Connect the mains plug (fitted at the factory) to the power supply
.
5.
Use the ‘Press the ON/OFF button’ to switch on the pump.
6. Select language:
Ä
Chapter 8.2 ‘Language selection’ on page 136
CAUTION!
When the pump is first started, NO ACCESS CODE is activated!
T
o exclude the possibility of the pump being used improperly and / or
of the system parameters being adjusted inadvertently, the pump
software must be protected by the integrated multi-stage
[access code] .
During the initial configuration of the pump, we strongly recommend
enabling the [access code] and make the set passwords only
available to authorised persons:
Ä
Chapter 7.10.4 ‘Access code’
on page 97
Setting the access code also protects the pump against
unauthorised access via a smartphone connected via Bluetooth.
An unprotected pump can be accessed without restriction via the
EcoAPP !
If an access code has been defined on the pump, the pump will only
be visible in the EcoAPP once the correct access code of the pump
has been entered in the EcoAPP settings.
7. Set operating mode:
Ä
Chapter 7.9 ‘Operating Mode’ on page 78
8. Perform calibration on initial commissioning:
Ä
Chapter 8.3 ‘Calibration on initial start-up’ on page 137
Start-up
135 417102276 Rev. 5-02.2020
