14.5 Electrical data
Name
Type
00510X
Type
01
110S
Type
03003M
Type
05010M
Type
12003M
Supply voltage [V / Hz] 100 - 240 ±10% / 50/60
Motor power [W] 30 50
IP Code IP65
Appliance class II
Inputs:
Level, external release, batch max. 24 V DC / 6 mA
Pulse, standard signal (0/4-20 mA) max. 25 mA (approx. 50 Ohm)
Minimum pulse duration (On/Off) 15 mS
Outputs:
Alarm (relay contact) 230 V, AC/DC, 3 A
Stroke signal (transistor) max. 24 V, DC, 200 mA
External power supply 5 V, max. 100 mA
Permissible cables:
Permissible external cable Ø for connecting the inputs/outputs:
AD Ø = 5.1-5.7 mm. LIYY 4x0.5; LIYY 5x0.34; L
YCY 2x0.34
Permissible cables: Oilflex 4x0.5
IP65 is applicable only when the specified cable is being used.
14.6 Tightening torques
NOTICE!
It is essential that the tightening torques given below are observed, firstly to
ensure the leak-tightness of the system and secondly to ensure the integrity
of the thread.
The tightening torques of the metering head screws are given on an
adhesive label that is af
fixed to the pump head.
Tightening torque of the suction/pressure valves:
Pump head size 5 l/h and 11 l/h 5 l/h and 11 l/h 5 l/h and 11 l/h
Tightening torque 2 ± 0.2 Nm 2,8 ± 0.2 Nm 4 ± 0.2 Nm
Tightening torque of the metering head screws:
Pump head size 5 l/h and 11 l/h 5 l/h and 11 l/h 5 l/h and 11 l/h
Tightening torque 3,75 ± 0.25 Nm 6 ± 0.25 Nm 6 ± 0.25 Nm
Technical specifications
185 417102276 Rev. 5-02.2020
