Software setting:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Fig. 37: Software setting: ‘Pulse’
1.
[Main menu] Press the button.
ð
The ‘Main menu
’ screen is displayed.
2. [Operating mode] .
ð
The screen for setting the [Operating mode] is displayed.
3. [Pulse] .
4.
[ Click Next] to save the setting.
ð
The screen for setting the ‘
Pulse interval’ is displayed.
5. Enter the quantity in litres (before the decimal point) using the scrollbar
.
6. ‘Select quantity after the decimal point
’ .
7. Enter the quantity in litres (after the decimal point) using the scrollbar
.
8.
[Click Next] to save the setting.
ð
The screen for selecting the ‘pulse memory
’ is displayed.
9. ‘Select pulse memory
’ .
ð
If the ‘pulse memory’ is active, a ü is displayed in the selection field.
10.
[Click Next] to save the setting.
ð
The screen for setting the‘concentration solution
’ is displayed.
11. Enter the concentration in % (before the decimal point) using the scrollbar
.
12. ‘Select concentration after the decimal point
’ .
13. Enter the concentration in % (after the decimal point) using the scrollbar
.
14.
Pressing the button saves and returns to the[Operating mode].
15.
Pressing the button returns to the [Main menu].
16.
By pressing the button, you can return to the [operating display].
Control / Software
83 417102276 Rev. 5-02.2020
