[Start Calibration] :
1.
[Call up the Main menu] :
Ä
Chapter 7.7 ‘Main menu’ on page 73
2.
[Select Configuration] :
Ä
Chapter 7.10 ‘Overview - Configuration’ on page 92
3. Using the scrollbar on the right side of the screen, scroll to the [Start Calibration]
.
4. [Select Start Calibration] .
ð
The screen changes to [Press start].
5. ‘Calibration
’ .
ð
The screen changes to ‘Calibration step 1’.
6. Calibration step 1 runs automatically
.
The calibration runs automatically in this step.
The pump completes a given number of pump-specific strokes and
counts them down to 0. At the same time, the oval gear meter (OGM)
pulses are also counted. The pump stops after the strokes elapse.
7. The ‘Calibration step 1
’ screen is displayed.
Enter the quantity in litres (before the decimal point) using the scrollbar.
8. Select the quantity in millilitres after the decimal point.
9. Enter the quantity in millilitres (after the decimal point) using the scrollbar
.
10.
Press the button Next.
ð
The screen changes to ‘Calibration step 2
’.
11. The ‘Calibration step 2
’ runs automatically.
The calibration sequence runs again automatically in this step.
12. The ‘Calibration step 2
’ screen is displayed.
Enter the quantity in litres (before the decimal point) using the scrollbar.
13. Select the quantity in millilitres after the decimal point.
14. Enter the quantity in millilitres (after the decimal point) using the scrollbar
.
15.
[ Click Next] .
ð
The setting is saved, and the screen switches back to the operation screen.
Control / Software
127 417102276 Rev. 5-02.2020
