Each of these six registers holds one part of the Network Management Vector. The length of the Network
Management Vector is configured in the Network Management Vector Length Register (NMVLR). If
NMVLR is programmed with a value less than 12 bytes, the remaining bytes of the Network Management
Vector Registers (NMVR0–NMVR5), which are not used for the Network Management Vector
accumulating, remains 0s.
The NMVR provides accrued information over all received NMVs in the last communication cycle. All
NMVs received in one cycle are ORed into the NMVR. The NMVR is updated at the end of the
communication cycle.
3.3.2.36 Network Management Vector Length Register (NMVLR)
This register defines the length of the network management vector in bytes.
Table 3-42. NMVR[0:5] Field Descriptions
Field Description
15–0
NMVP
Network Management Vector Part — The mapping between the Network Management Vector Registers
(NMVR0–NMVR5) and the receive message buffer payload bytes in NMV[0:11] is depicted in Table 3-43.
Table 3-43. Mapping of NMVRn to the Received Payload Bytes NMVn
NMVRn Register NMVn Received Payload
NMVR0.NMVP[15:8] NMV0
NMVR0.NMVP[7:0] NMV1
NMVR1.NMVP[15:8] NMV2
NMVR1.NMVP[7:0] NMV3
...
NMVR5.NMVP[15:8] NMV10
NMVR5.NMVP[7:0] NMV11
0x0058 Write: POC:config
1514131211109876543210
R000000000000
NMVL
W
Reset0000000000000000
Figure 3-35. Network Management Vector Length Register (NMVLR)
Table 3-44. NMVLR Field Descriptions
Field Description
3–0
NMVL
Network Management Vector Length — protocol related variable: gNetworkManagementVectorLength
This field defines the length of the Network Management Vector in bytes. Legal values are between 0 and 12.
