3.3.2.38 Timer 1 Cycle Set Register (TI1CYSR)
This register defines the cycle filter value and the cycle filter mask for timer T1. For a detailed description
of timer T1, refer to Section 3.4.17.1, “Absolute Timer T1”.
NOTE
If the application modifies the value in this register while the timer is
running, the change becomes effective immediately and timer T1 expires
according to the changed value.
3.3.2.39 Timer 1 Macrotick Offset Register (TI1MTOR)
This register holds the macrotick offset value for timer T1. For a detailed description of timer T1, refer to
Section 3.4.17.1, “Absolute Timer T1”.
NOTE
If the application modifies the value in this register while the timer is
running, the change becomes effective immediately and timer T1 expires
according to the changed value.
0x005C Write: Any Time
1514131211109876543210
R0 0
T1_CYC_VAL
00
T1_CYC_MSK
W
Reset0000000000000000
Figure 3-37. Timer 1 Cycle Set Register (TI1CYSR)
Table 3-46. TI1CYSR Field Descriptions
Field Description
13–8
T1_CYC_VAL
Timer T1 Cycle Filter Value — This field defines the cycle filter value for timer T1.
5–0
T1_CYC_MSK
Timer T1 Cycle Filter Mask — This field defines the cycle filter mask for timer T1.
0x005E Write: Any Time
1514131211109876543210
R0 0
T1_MTOFFSET
W
Reset0000000000000000
Figure 3-38. Timer 1 Macrotick Offset Register (TI1MTOR)
Table 3-47. TI1MTOR Field Descriptions
Field Description
13–0
T1_MTOFFSET
Timer 1 Macrotick Offset — This field defines the macrotick offset value for timer 1.
