3.3.2.55 Receive FIFO Message ID Acceptance Filter Mask Register (RFMIAFMR)
This register defines the filter mask for the message ID acceptance filter of the selected receive FIFO. For
details on message ID filtering see Section 3.4.9.5, “Receive FIFO filtering”.
3.3.2.56 Receive FIFO Frame ID Rejection Filter Value Register (RFFIDRFVR)
This register defines the filter value for the frame ID rejection filter of the selected receive FIFO. For
details on frame ID filtering see Section 3.4.9.5, “Receive FIFO filtering”.
3.3.2.57 Receive FIFO Frame ID Rejection Filter Mask Register (RFFIDRFMR)
This register defines the filter mask for the frame ID rejection filter of the selected receive FIFO. For
details on frame ID filtering see Section 3.4.9.5, “Receive FIFO filtering”.
0x0092 Write: POC:config
1514131211109876543210
R
MIDAFMSK
W
Reset0000000000000000
Figure 3-54. Receive FIFO Message ID Acceptance Filter Mask Register (RFMIAFMR)
Table 3-66. RFMIAFMR Field Descriptions
Field Description
15–0
MIDAFMSK
Message ID Acceptance Filter Mask — Filter mask for the message ID acceptance filter.
0x0094 Write: POC:config
1514131211109876543210
R00000
FIDRFVAL
W
Reset0000000000000000
Figure 3-55. Receive FIFO Frame ID Rejection Filter Value Register (RFFIDRFVR)
Table 3-67. RFFIDRFVR Field Descriptions
Field Description
10–0
FIDRFVAL
Frame ID Rejection Filter Value — Filter value for the frame ID rejection filter.
0x0096 Write: POC:config
1514131211109876543210
R00000
FIDRFMSK
W
Reset0000000000000000
Figure 3-56. Receive FIFO Frame ID Rejection Filter Mask Register (RFFIDRFMR)
