FlexRay Module (FLEXRAYV4)

MFR4310 Reference Manual, Rev. 2

Freescale Semiconductor 125

3.3.2.62.9 Protocol Configuration Register 8 (PCR8)

3.3.2.62.10 Protocol Configuration Register 9 (PCR9)

3.3.2.62.11 Protocol Configuration Register 10 (PCR10)

3.3.2.62.12 Protocol Configuration Register 11 (PCR11)

0x00B0 Write: POC:config

1514131211109876543210

max_without_clock_

correction_fatal

max_without_clock_

correction_passive

wakeup_symbol_tx_idle

Reset0000000000000000

Figure 3-69. Protocol Configuration Register 8 (PCR8)

0x00B2 Write: POC:config

1514131211109876543210

mini

slot_

exists

sym

bol_

win

dow_

exists

offset_correction_out

Reset0000000000000000

Figure 3-70. Protocol Configuration Register 9 (PCR9)

0x00B4 Write: POC:config

1514131211109876543210

R single

_slot

_en

abled

wake

up_

chan

nel

macro_per_cycle

Reset0000000000000000

Figure 3-71. Protocol Configuration Register 10 (PCR10)

0x00B6 Write: POC:config

1514131211109876543210

Rkey_

slot_

used_

for_

start

key_

slot_

used_

for_

sync

offset_correction_start

Reset0000000000000000

Figure 3-72. Protocol Configuration Register 11 (PCR11)
