Port Integration Module (PIM)
MFR4310 Reference Manual, Rev. 2
214 Freescale Semiconductor
4.3.1.7 Physical Layer Pins Pullup/pulldown Enable Register (PLPPER)
This register enables/disables the pullups/pulldowns of the FlexRay physical layer pins.
5
A6/XADDR14
AMI/MPC address bit 6 / HCS12 expanded address bit 14 pullup/pulldown control
0 pulldown
1 pullup
6
A[10:7]
AMI/MPC address bits 7 through 10 pullup/pulldown control
0 pulldown
1 pullup
7
BSEL[1:0]#
AMI/MPC byte select pullup/pulldown control
0 pulldown
1 pullup
8
OE#/ACS0
AMI/MPC output enable / HCS12 address select bit 0 pullup/pulldown control
0 pulldown
1 pullup
9
A11/ACS1
AMI/MPC address bit 11 / HCS12 address select bit 1 pullup/pulldown control
0 pulldown
1 pullup
10
A12/ACS2
AMI/MPC address bit 12 / HCS12 address select bit 2 pullup/pulldown control
0 pulldown
1 pullup
11
D[0:15]/
PA[0:7]/PB[0:7]
Host interface input data pullup/pulldown control
0 pulldown
1 pullup
12
CE#/LSTRB
AMI/MPC chip enable / HCS12 low-byte strobe pullup/pulldown control
0 pulldown
1 pullup
13
WE#/RW_CC#
AMI write enable / HCS12 read/write select pullup/pulldown control
0 pulldown
1 pullup
Address in MFR4310 = 0x00FC Write: Any Time
1514131211109876543210
R00000000000000
RXD_BG2 RXD_BG1
W
Reset0000000000000000
Figure 4-7. Physical Layer Pins Pullup/pulldown Enable Register (PLPPER)
Table 4-7. HIPPCR Field Descriptions (continued)
Field Description
