FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
120 Freescale Semiconductor
3.3.2.60 Last Dynamic Transmit Slot Channel A Register (LDTXSLAR)
This register provides the number of the last transmission slot in the dynamic segment for channel A. This
register is updated after the end of the dynamic segment and before the start of the next communication
cycle.
Table 3-70. RFRFCTR Field Descriptions
Field Description
11
F3MD
Range Filter 3 Mode — This control bit defines the filter mode of the frame ID range filter 3.
0 range filter 3 runs as acceptance filter
1 range filter 3 runs as rejection filter
10
F2MD
Range Filter 2 Mode — This control bit defines the filter mode of the frame ID range filter 2.
0 range filter 2 runs as acceptance filter
1 range filter 2 runs as rejection filter
9
F1MD
Range Filter 1 Mode — This control bit defines the filter mode of the frame ID range filter 1.
0 range filter 1 runs as acceptance filter
1 range filter 1 runs as rejection filter
8
F0MD
Range Filter 0 Mode — This control bit defines the filter mode of the frame ID range filter 0.
0 range filter 0 runs as acceptance filter
1 range filter 0 runs as rejection filter
3
F3EN
Range Filter 3 Enable — This control bit is used to enable and disable the frame ID range filter 3.
0 range filter 3 disabled
1 range filter 3 enabled
2
F2EN
Range Filter 2 Enable — This control bit is used to enable and disable the frame ID range filter 2.
0 range filter 2 disabled
1 range filter 2 enabled
1
F1EN
Range Filter 1 Enable — This control bit is used to enable and disable the frame ID range filter 1.
0 range filter 1 disabled
1 range filter 1 enabled
0
F0EN
Range Filter 0 Enable — This control bit is used to enable and disable the frame ID range filter 0.
0 range filter 0 disabled
1 range filter 0 enabled
0x009C
1514131211109876543210
R00000 LASTDYNTXSLOTA
W
Reset0000000000000000
Figure 3-59. Last Dynamic Slot Channel A Register (LDTXSLAR)
Table 3-71. LDTXSLAR Field Descriptions
Field Description
10–0
LASTDYNTX
SLOTA
Last Dynamic Transmission Slot Channel A — protocol related variable: zLastDynTxSlot channel A
Number of the last transmission slot in the dynamic segment for channel A. If no frame was transmitted during
the dynamic segment on channel A, the value of this field is set to 0.
