3.3.2.44 Slot Status Registers (SSR0–SSR7)
Each of these eight registers holds the status vector of the slot specified in the corresponding internal slot
status selection register, which can be programmed using the Slot Status Selection Register (SSSR). Each
register is updated after the end of the corresponding slot as shown in Figure 3-138. The register bits are
directly related to the protocol variables and described in more detail in Section 3.4.18, “Slot Status
Monitoring”.
0x0068 (SSR0)
0x006A (SSR1)
0x006C (SSR2)
0x006E (SSR3)
0x0070 (SSR4)
0x0072 (SSR5)
0x0074 (SSR6)
0x0076 (SSR7)
1514131211109876543210
R VFB SYB NFB SUB SEB CEB BVB TCB VFA SYA NFA SUA SEA CEA BVA TCA
W
Reset0000000000000000
Figure 3-43. Slot Status Registers (SSR0–SSR7)
Table 3-54. SSR0–SSR7 Field Descriptions
Field Description
15
VFB
Valid Frame on Channel B — protocol related variable: vSS!ValidFrame channel B
0 vSS!ValidFrame = 0
1 vSS!ValidFrame = 1
14
SYB
Sync Frame Indicator Channel B — protocol related variable: vRF!Header!SyFIndicator channel B
0 vRF!Header!SyFIndicator = 0
1 vRF!Header!SyFIndicator = 1
13
NFB
Null Frame Indicator Channel B — protocol related variable: vRF!Header!NFIndicator channel B
0 vRF!Header!NFIndicator = 0
1 vRF!Header!NFIndicator = 1
12
SUB
Startup Frame Indicator Channel B — protocol related variable: vRF!Header!SuFIndicator channel B
0 vRF!Header!SuFIndicator = 0
1 vRF!Header!SuFIndicator = 1
11
SEB
Syntax Error on Channel B — protocol related variable: vSS!SyntaxError channel B
0 vSS!SyntaxError = 0
1 vSS!SyntaxError = 1
10
CEB
Content Error on Channel B — protocol related variable: vSS!ContentError channel B
0 vSS!ContentError = 0
1 vSS!ContentError = 1
9
BVB
Boundary Violation on Channel B — protocol related variable: vSS!BViolation channel B
0 vSS!BViolation = 0
1 vSS!BViolation = 1
8
TCB
Transmission Conflict on Channel B — protocol related variable: vSS!TxConflict channel B
0 vSS!TxConflict = 0
1 vSS!TxConflict = 1
