FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
112 Freescale Semiconductor
3.3.2.45 Slot Status Counter Registers (SSCR0–SSCR3)
Each of these four registers provides the slot status counter value for the previous communication cycle(s)
and is updated at the cycle start. The provided value depends on the control bits and fields in the related
internal slot status counter condition register SSCCRn, which can be programmed by using the Slot Status
Counter Condition Register (SSCCR). For more details, see Section 3.4.18.4, “Slot Status Counter
Registers”.
7
VFA
Valid Frame on Channel A — protocol related variable: vSS!ValidFrame channel A
0 vSS!ValidFrame = 0
1 vSS!ValidFrame = 1
6
SYA
Sync Frame Indicator Channel A — protocol related variable: vRF!Header!SyFIndicator channel A
0 vRF!Header!SyFIndicator = 0
1 vRF!Header!SyFIndicator = 1
5
NFA
Null Frame Indicator Channel A — protocol related variable: vRF!Header!NFIndicator channel A
0 vRF!Header!NFIndicator = 0
1 vRF!Header!NFIndicator = 1
4
SUA
Startup Frame Indicator Channel A — protocol related variable: vRF!Header!SuFIndicator channel A
0 vRF!Header!SuFIndicator = 0
1 vRF!Header!SuFIndicator = 1
3
SEA
Syntax Error on Channel A — protocol related variable: vSS!SyntaxError channel A
0 vSS!SyntaxError = 0
1 vSS!SyntaxError = 1
2
CEA
Content Error on Channel A — protocol related variable: vSS!ContentError channel A
0 vSS!ContentError = 0
1 vSS!ContentError = 1
1
BVA
Boundary Violation on Channel A — protocol related variable: vSS!BViolation channel A
0 vSS!BViolation = 0
1 vSS!BViolation = 1
0
TCA
Transmission Conflict on Channel A — protocol related variable: vSS!TxConflict channel A
0 vSS!TxConflict = 0
1 vSS!TxConflict = 1
0x0078 (SSCR0)
0x007A (SSCR1)
0x007C (SSCR2)
0x007E (SSCR3)
1514131211109876543210
R SLOTSTATUSCNT
W
Reset0000000000000000
Figure 3-44. Slow Status Counter Registers (SSCR0–SSCR3)
Table 3-54. SSR0–SSR7 Field Descriptions (Continued)
Field Description
