Freescale Semiconductor FlexRay MFR4310 - Figure 3-21. Macrotick Counter Register (MTCTR); Figure 3-22. Cycle Counter Register (CYCTR); Table 3-29. MTCTR Field Descriptions; Table 3-30. CYCTR Field Descriptions

FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
96 Freescale Semiconductor
3.3.2.22 Macrotick Counter Register (MTCTR)
This register provides the macrotick count of the current communication cycle.
3.3.2.23 Cycle Counter Register (CYCTR)
This register provides the number of the current communication cycle.
1
ASEA
Aggregated Syntax Error on Channel A — This flag is set when a syntax error has been detected on channel
A. Syntax errors are detected in the communication slots, the symbol window, and the NIT.
0 No syntax error detected
1 Syntax errors detected
0
AVFA
Aggregated Valid Frame on Channel A — This flag is set when a syntactically correct valid frame has been
received in any static or dynamic slot through channel A.
0 No syntactically valid frames received
1 At least one syntactically valid frame received
0x0030
1514131211109876543210
R0 0 MTCT
W
Reset0000000000000000
Figure 3-21. Macrotick Counter Register (MTCTR)
Table 3-29. MTCTR Field Descriptions
Field Description
13–0
MTCT
Macrotick Counter — protocol related variable: vMacrotick
This field provides the macrotick count of the current communication cycle.
0x0032
1514131211109876543210
R0000000000 CYCCNT
W
Reset0000000000000000
Figure 3-22. Cycle Counter Register (CYCTR)
Table 3-30. CYCTR Field Descriptions
Field Description
5–0
CYCCNT
Cycle Counter — protocol related variable: vCycleCounter
This field provides the number of the current communication cycle. If the counter reaches the maximum value of
63, the counter wraps and starts from zero again.
Table 3-28. PSR3 Field Descriptions (Continued)
Field Description
