FlexRay Module (FLEXRAYV4)
MFR4310 Reference Manual, Rev. 2
Freescale Semiconductor 97
3.3.2.24 Slot Counter Channel A Register (SLTCTAR)
This register provides the number of the current slot in the current communication cycle for channel A.
3.3.2.25 Slot Counter Channel B Register (SLTCTBR)
This register provides the number of the current slot in the current communication cycle for channel B.
3.3.2.26 Rate Correction Value Register (RTCORVR)
This register provides the sign extended rate correction value in microticks as it was calculated by the clock
synchronization algorithm. The FlexRay module updates this register during the NIT of each odd
numbered communication cycle.
0x0034
1514131211109876543210
R00000 SLOTCNTA
W
Reset0000000000000000
Figure 3-23. Slot Counter Channel A Register (SLTCTAR)
Table 3-31. SLTCTAR Field Descriptions
Field Description
10–0
SLOTCNTA
Slot Counter Value for Channel A — protocol related variable: vSlotCounter for channel A
This field provides the number of the current slot in the current communication cycle.
0x0036
1514131211109876543210
R00000 SLOTCNTB
W
Reset0000000000000000
Figure 3-24. Slot Counter Channel B Register (SLTCTBR)
Table 3-32. SLTCTBR Field Descriptions
Field Description
10–0
SLOTCNTA
Slot Counter Value for Channel B — protocol related variable: vSlotCounter for channel B
This field provides the number of the current slot in the current communication cycle.
0x0038 Additional Reset: RUN Command
1514131211109876543210
RRATECORR
W
Reset0000000000000000
Figure 3-25. Rate Correction Value Register (RTCORVR)
